Marque: Whirlpool
Modèle: 1456^2A - GAS RANGE
06 - OVEN DOOR
| # sur le plan | # de pièce | Description | Remplacement | Prix | ||
|---|---|---|---|---|---|---|
| 1 | 327320 | Screw 10-16x7/16`` | ||||
| 2 | 327809 | Wire Shield | ||||
| 3 | 330613 | Main Back | ||||
| 4 | 329146 | Insulation-Oven Back & Bottom (1 Piece) | ||||
| 5 | 328959 | Retainer-Insulation (Lt. or Rt.) | ||||
| 6 | 330340 | Trim-Side (Left) | ||||
| 6 | 330341 | Trim-Side (Right) | ||||
| 7 | 326102 | Body Side (Lt. or Rt.) (Black) | ||||
| 8 | 326974 | Screw 10AB | ||||
| 9 | 326965 | Spring-Oven Door (Lt. or Rt.) | 4335115 | |||
| 10 | 326013 | Hinge-Oven Door (Left) | ||||
| 10 | 326012 | Hinge-Oven Door (Right) | ||||
| 11 | 334971 | Base w/Levelers (Lt. or Rt.) | ||||
| 12 | 112013 | Screw 10-32 x 5/8`` | ||||
| 13 | 335065 | Lining-Storage Door | ||||
| 14 | 335061 | Strike-Door | ||||
| 15 | 335060 | Catch-Door | ||||
| 16 | 326052 | Leg Leveler (4 Req) | ||||
| 17 | 312605 | BLOC D'ALIMENTATION | 330031 | 15,26$ | ||
| 18 | 328491 | Storage Compartment | ||||
| 19 | 331144 | Lower Insulation Retainer | ||||
| 20 | 330166 | Insulation | ||||
| 21 | 327808 | Wire Shield | ||||
| 22 | 324257 | Bushing | ||||
| 23 | 330978 | Flue Deflector | ||||
| 24 | 329147 | Insulation-Oven Top & Sides (1 Piece) | ||||
| 25 | 327781 | Flue Box | ||||
| 26 | 331568 | Oven Body | ||||
| 27 | 304835 | Cover | ||||
| 28 | 321539 | Clip-Thermostat Bulb (2 Rew) | ||||
| 29 | 87883 | Holder-Oven Light Bulb | ||||
| 30 | 335069 | Front Frame | ||||
| 31 | 302343 | spacer-handle | ||||
| 32 | 335059 | Bracket-Catch | ||||
| 33 | 316849 | Screw-10-32x1/2`` | ||||
| 34 | 327320 | Screw 10-16x7/16`` | ||||
| 35 | 326292 | Front Panel-Storage Door | ||||
| 36 | 292240 | Handle-Storage Door | ||||
| 37 | 335197 | Shield-Thermostat Bulb | ||||
| 38 | 335231 | Oven Bottom | ||||
| 39 | 229372 | Retainer-Oven Light Lens | ||||
| 40 | 114989 | Lens-Oven Light | ||||
| 41 | 229371 | Gasket-Lens | ||||
| 42 | 111257 | Oven Light Bulb | ||||
| 43 | 237762 | Cover Plate-Thermostat Bulb | ||||
| 44 | 326069 | Oven Rack (2 Req) | ||||
| 45 | 331592 | Broiler Pan | ||||
| 46 | 326297 | Broiler Pan Grid | ||||
| 47 | 330120 | Frame-Front Panel | ||||
| 48 | 335058 | Hinge-Door | ||||
| 49 | 335332 | Shield-Flue Deflector | ||||
| 50 | 327621 | Screw 6-20x3/8`` | ||||
| 51 | 331512 | Extension Side Trim |
*Le prix peut changer sans préavis
