Brand: Electrolux

Model: EW28BS87SS3 - REFRIGERATOR, FRENCH DOOR, BOTTOM FREEZER, W/DISPE

01 - COVER SHEET

EW28BS87SS3
Plan number Part Number Description Replacement Price
1 5304501270 GASKET,FREEZER DRAWER,GRAY   $203.20
11 241987960 DOOR   $444.85
18 241881310 HANDLE FRZR DRAWER STAINLESS   $277.95
21 241690602 SCREW   $10.90
21A 241953902 SCREW 8 18 X .380   $17.40
21B 242015001 SCREW 10 8 19 X 1/2   $16.70
24 240383412 SCREW,TRUSS HD QUAD,#10-15   $11.60
49 5304508733 BASKET-FRZR,LOWER 5304525892   $190.85
49A 241780810 BASKET,FREEZER,UPPER   $231.50
50 5304501271 CLIP,FREEZER BASKET   $15.95
51 5304507978 SLIDE ASSY,LOWER BASKET   $245.30
NIA 242039702 SCREW   $4.35
51A 5304508096 SLIDE ASSEMBLY,FREEZER BASKET   $134.25
NIAA 242039701 SCREW   $13.80
52 5304507979 SLIDE ASSEM,BASKET LOWER LH   $244.55
52A 5304508097 SLIDE ASSEMBLY,FREEZER BASKET   $137.15
53 5304508271 RETAINER, BASKET SET OF FOUR 5303918801   $12.35
79 218755401 SCREW SET   $23.95
NIA 5304508270 WRENCH,ALLEN,SET SCREW   $18.15
80 218755504 SCREW-SHOULDER   $13.80
82 5304503705 DIVIDER,BASKET,LOWER   $121.20
84 241780904 DIVIDER,BASKET   $68.20
85 242130901 DIVIDER,BASKET,LOWER   $87.80
NIA 242139201 SPRING-COMPRESSION,DIVIDER,LOW   $18.85
85A 242139301 SUPPORT-BEAM,DIVIDER,LOWER BAS   $75.50
86 5304507340 BAR   $45.70
NIA 242011101 PIN LOCK   $14.50
87 5304507999 PINION   $10.15
88 241824008 RACK-TILT OUT,DOOR WHITE   $118.30
89 5304509676 BRACKET,FREEZER DRAWER   $74.05
NIA 241979601 BUMPER RUBBER   $23.25
90 241770702 BAR,TIMING 241770705   $41.80
91 241824102 CAP DOOR RACK   $16.70
91A 241824101 CAP DOOR RACK WHITE   $16.70
105 242116801 TRIM,BASKET   $18.15
NI 242146401 SCREW,SER HEX WASH HD,1/4-20 X   $14.50
*The price can change whitout warning
