Brand: Whirlpool

Model: WET4124HW0 - COOKTOP, GAS, 36 INCH

02 - FREEZER DRAWER, BASKETS

WET4124HW0
Plan number Part Number Description Replacement Price
1 241778308 GASKET,FREEZER DRAWER,GRAY 5304501270   $203.20
11 241987921 DOOR COMPLETE FREEZER SS   $546.95
18 242029401 DOOR, HANDLE   $203.20
NIA 241601001 HEXAGONAL KEY 5304467131   $23.25
21 241690602 SCREW   $10.90
21A 241953902 SCREW 8 18 X .380   $17.40
21C 241899703 SCREW,TRUSS HEAD,#10-32 X 1/4   $15.25
24 240383406 SCREW TRUSS HD QUAD 5304515677   $8.70
24A 240383412 SCREW,TRUSS HD QUAD,#10-15   $11.60
49 242130801 BASKET-FRZR,LOWER 5304526200   $155.90
49A 241780811 BASKET-FRZR,UPPER   $224.95
51 242147108 SLIDE ASSY,RH,LWR BASKET 5303918694   $221.35
NIA 242039702 SCREW   $4.35
51A 241894221 SLIDE ASSY,BASKET,RH,FZ   $136.45
NIAA 242039701 SCREW   $13.80
52 242147107 SLIDE ASSY,LH,LWR BASKET 5303918693   $245.30
52A 241894222 SLIDE ASSY,BASKET,LH,FZ   $137.15
53A 242216301 RETAINER, BASKET SET OF FOUR 5303918801   $12.35
79 218755407 SCREW-SET 218755402   $6.55
82 242131401 DIVIDER,BASKET   $63.05
84 241780905 DIVIDER,BASKET   $0.00
85 242139401 DIVIDER,BASKET,LOWER   $83.45
NIA 242139201 SPRING-COMPRESSION,DIVIDER,LOW   $18.85
85A 242139301 SUPPORT-BEAM,DIVIDER,LOWER BAS   $75.50
85B 241872203 SUPPORT-BEAM,LOWER BASKET   $51.55
86 241807605 BAR 5304507340   $45.70
NIA 242011101 PIN LOCK   $14.50
89 241972302 BRACKET-FREEZER DRAWER   $104.50
NIA 242147601 PLATE,TAPPING 5304497384   $15.95
90 242136901 BALANCE BAR   $36.30
102 242029301 BLOCK   $25.40
103 242077302 SCREW,INCLUDES BOLTS   $8.00
105 242116801 TRIM,BASKET   $18.15
NI 241953901 SCREW,CONTROL MTG 5304453707   $15.25
NI 242015001 SCREW 10 8 19 X 1/2   $16.70
NI 242146401 SCREW,SER HEX WASH HD,1/4-20 X   $14.50
1 W10882346 WASHPLATE W10882404   $216.03
2 W10882362 SCREW-KIT W11577483   $11.19
3 W10882370 SCREW-KIT W11577483   $11.19
4 W10882372 WASHER W10882661   $6.02
5 W10882109 RING,TUB   $142.07
6 W10869499 SCREW   $19.50
7 W11187713 TUB, ADAPTER   $0.00
8 W11187715 PLUG, HOLE   $0.00
9 W11178918 WIRE, GROUND (MOTOR)   $0.00
10 W11178811 BASKET   $233.30
11 W11178825 FILTER W11684623   $16.10
12 W11178822 RETAINER, LINT FILTER   $0.00
13 W10869502 SCREW W11296992   $11.43
14 W11178813 SCREW   $0.00
15 W11209824 TUBE   $84.50
16 W11174583 SUSPENSION   $156.69
17 W10882132 TUB-OUTER   $0.00
18 W11178808 CAP   $11.38
19 W10883610 CLAMP-HOSE   $19.22
20 W10882407 HOSE   $39.31
21 W10882410 SLEEVE   $38.61
22 W11178915 WIRE, GROUND   $0.00
23 W11176555 SCREW   $0.00
24 W10883819 TIE-WIRE   $19.22
25 W10883783 GEARCASE W11665996   $329.71
26 W10883787 SCREW   $19.73
27 W10883753 SCREW   $20.93
28 W11187717 ACTUATOR W11614637   $90.90
29 W10883805 SCREW   $19.36
30 W11178899 CAM-BRAKE   $23.99
31 W11178900 CAM-BRAKE   $23.99
32 W10883809 BRACKET   $34.17
33 W10882000 SCREW   $19.36
34 W10883812 ISOLATOR   $19.29
35 W10883817 SCREW   $20.08
36 W11178896 MOTOR-DRVE W11189163   $329.60
37 W10882138 PULLEY   $73.49
38 W10882141 BELT W11676809   $19.74
39 W10882148 BRACKET   $87.43
40 W10883826 SCREW   $19.73
*The price can change whitout warning
