Brand: Whirlpool

Model: WET4124HW0 - COOKTOP, GAS, 36 INCH

03 - CABINET/TOP

WET4124HW0
Plan number Part Number Description Replacement Price
2 131168200 SCREW   $14.50
4 5304515236 MOTOR CONTROL,ASSEMBLY,W/COVER   $307.00
NIA 5304514805 HARNESS,WIRING MAIN,W/DRUM LIG 5304522537   $198.85
NIB 134178901 SCREW, 8-18AB X 0.455 WG04A01528   $0.00
6 137262100 SCREW-10-14X1,PH QUAD   $10.15
7 5304505144 COVER,HINGE HOLES   $4.20
8 5304514774 DOOR LOCK   $121.90
NIA 5304505176 HARNESS,WIRING,DOOR LOCK DBL 5304522524   $58.80
8A 5304505103 COVER,DOOR LOCK,FRONT FLANGE   $249.65
9 131477000 SCREW 131168200   $14.50
10 137241000 SCREW,QUAD PH,10-16 X 0.375   $10.90
11 5304505107 GLASS,DOOR   $226.40
12 5304505234 FRAME,DOOR,INNER   $164.00
14 5304505088 LATCH,DOOR   $26.15
15 5304508699 HINGE   $103.80
16 137087000 SCREW,10--16X.75   $11.60
17 5304505102 CLIP,FRONT PANEL,(4)   $13.80
18 5304505259 SCREW,QUAD PH TYPE A,M5 X 0.8   $13.80
19 5304505441 SCREW,PPH B,6-20X.375   $6.55
21 137087400 SCREW,#10-16 X .625   $10.90
22 5304505101 BRACKET,SPRING,(2)   $13.05
23 5304505139 PANEL,SIDE,WHITE,(2)   $239.50
24 5304505081 TOP PANEL,WHITE   $224.95
25 134646003 BASE   $211.20
26 134646112 PANEL,BACK 134646114   $205.40
27 5304505104 PROTECTION,DOOR LOCK   $14.50
28 134646201 PANEL,SERVICE,BACK 134646203   $14.50
29 5304505058 WASHER FRONT PANEL,WHITE   $250.35
31 5304505202 POWER CORD,ELECTRIC SVCE 5304522525   $51.55
32 5303209428 BUSHING - CORD   $17.40
36 134639100 LEVELLING SCREW   $31.95
37 134617600 BUSHING   $34.85
38 134639200 NUT,LEVELING LEG,BUSHING   $32.65
40 5304505328 CAP,DOOR VENT   $15.95
41 5304505329 SPRING,DOOR VENT   $15.95
42 5304505381 MAGNET,DOOR VENT   $20.35
43 5304505331 BUTTON,DOOR VENT 5304535443   $0.90
48 5304505389 FRAME,DOOR,EXTERNAL   $285.20
50 5304505087 BRACKET,TUB SUSPENSION   $54.45
51 5304505221 PROTECTOR,TUB BRACKET,SPRING H   $15.95
52 131931202 DAMPENER, VIBRATION, FOAM WG04F06352   $0.00
55 3205150 SCREW   $3.65
56 5304505001 BRACKET,HINGE   $49.35
57 5304505269 PIN,HINGE   $15.95
59 5304505311 SUPPORT,CONNECTOR   $11.60
60 5304514806 GROMMET,DISPENSER,BACK PANEL   $8.70
61 134652000 DAMPER,MASS VIBRATION   $370.85
NIA 137110800 CUSHION SHOCK BRACKET LEFT REA   $13.80
NIB 131202300 SCREW   $13.80
64 5304514807 DEFLECTOR,WATER   $29.75
NI 137146700 SHIPPING SUPPORT KIT   $164.00
NI 134876500 CLIP,SHIPPING CLAMP,REAR-PANEL 134876501   $20.35
NI 134591400 HOLE,PLUG   $21.80
NI 5303321209 WIRE TIE,6" 5304464772   $10.90
NI 134477400 SCREW,SHEET METAL,6-20 X 0.375   $13.05
NI 134629400 SCREW,MC5X8.5 TORX ,CABINET MT   $13.05
  $0.00
*The price can change whitout warning
