Brand: Maytag
Model: ACF3325AC (BOM: PACF3325AC0) - 30`` ELECTRIC CERAN FREESTANDING RANGE SELF CLEAN
03 - Maintop and Gas Supply
- 01 - Cabinet
- 03 - Maintop and Gas Supply
- 04 - Oven Door and Storage Drawer
- REFRIGERATOR DOOR PARTS
| Plan number | Part Number | Description | Replacement | Price | ||
|---|---|---|---|---|---|---|
| 1 | 32012205GY | GRATE, SINGLE CAST (DARK GRAY) | $0.00 | |||
| 2 | 31782603GY | CAP-BURNER | $30.83 | |||
| 3 | Y0315768 | TOP BURNER (MEDIUM 9K) | WPY0315768 | $119.87 | ||
| 4 | Y0316773 | ELECTRODE,BRACKET | WPY0316773, WG02F09060 | $40.68 | ||
| 5 | Y0316775 | SCREW, ELECTRODE | $0.00 | |||
| 6 | 31782503GY | CAP, BURNER 5K (DARK GREY) | $0.00 | |||
| 7 | 31750320 | SCREW | WPY04100059 | $6.31 | ||
| 8 | Y0315769 | TOP BURNER (SMALL 5K) | $0.00 | |||
| 9 | 31782703GY | CAP-BURNER | $35.24 | |||
| 10 | Y0315767 | TOP BURNER (LARGE 12/13K) | $0.00 | |||
| 11 | 31949103C | MAINTOP, GAS (BSQ) | $0.00 | |||
| 12 | 31750709 | SCREW, STUD | $0.00 | |||
| 13 | 31750701 | SCREW | W11245710 | $12.16 | ||
| 14 | 31945301 | BRKT, VENTURI MTG | $0.00 | |||
| 15 | 31899501 | TUBE, VENTURI-LEFT REAR | $0.00 | |||
| 16 | 31899401 | TUBE, VENTURI-FRONT | $0.00 | |||
| 17 | 31899502 | TUBE, VENTURI-RIGHT REAR | $0.00 | |||
| 18 | 31750712 | SCREW | WP8273096 | $6.63 | ||
| 19 | 31985501 | MANIFOLD PIPE | $0.00 | |||
| 20 | Y0315960 | VALVE, GAS 270 DEG (5K BTU) | $0.00 | |||
| 21 | 31983802 | VALVE, GAS 270 DEG (9.7K BTU) | $0.00 | |||
| 22 | 31985101 | VALVE, GAS 270 DEG (12K BTU) | $0.00 | |||
| 23 | 31962001 | HARNESS, SPARK SWITCH | $0.00 | |||
| 24 | 32045502 | BRACKET, MANIFOLD MTG | $0.00 | |||
| 25 | 31750410 | SCREW | W11245710 | $12.16 | ||
| 26 | 32077401 | KNOB HEAT SHIELD | $0.00 | |||
| 27 | 31926608C | KNOB, BURNER-270 DEGREE (BSQ) | $0.00 | |||
| 28 | 31936909C | MANIFOLD PANEL-SCREENED (BSQ) | $0.00 | |||
| 29 | 31750507 | SCREW | WP7101P126-60 | $5.61 | ||
| 30 | 32081601 | PLATE, BROIL ORIFICE | $0.00 | |||
| 31 | 31946201 | ELBOW, ORIFICE-No.54 HOOD | $0.00 | |||
| 32 | 31991701 | IGNITOR-F | WP7432P136-60 | $105.45 | ||
| 33 | 31968601 | ASSY, BROIL BURNER | $0.00 | |||
| 34 | 31957101 | BRACKET, IGNITER MOUNTING | $0.00 | |||
| 35 | 32054401 | BRACKET, DUAL VALVE | $0.00 | |||
| 36 | 31946901 | VALVE, GAS SAFETY | $0.00 | |||
| 37 | 31945701 | BURNER, BAKE | $0.00 | |||
| 38 | 31957001 | W/A BAKE IGNITER MTG | $0.00 | |||
| 39 | 31991701 | IGNITOR-F | WP7432P136-60 | $105.45 | ||
| 40 | 31947001 | REGULATOR, PRESSURE | $0.00 | |||
| 41 | 31945901 | TUBING, VALVE TO REGULATOR | $0.00 | |||
| 42 | 31948201 | BRKT, MTG-PRESSURE REGULATOR | $0.00 | |||
| 43 | 31946001 | TUBING, VALVE TO BROIL | $0.00 | |||
| 44 | 31946101 | TUBING, MANIFOLD TO REGULATOR | $0.00 | |||
| NI | 32074601 | SPACER, BROIL | $0.00 | |||
| NI | 32080601 | CLIP, BROIL SPACER | $0.00 |
*The price can change whitout warning
