Brand: Maytag
Model: GC2228EED9 - REFRIGERATOR
11 - ICE BIN (REV 11)
- 01 - COMPRESSOR (GC2228EED9-REV 17)
- 02 - COMPRESSOR (GC2228EEDB/W/3/5/9-REV 10)
- 04 - DRAWER PARTS
- 04 - DRYER CABINET AND MOTOR PARTS
- 04 - FOUNTAIN
- 06 - DOOR (LDE7500ACE,ADE) & (LDG)
- 06 - FREEZER INNER DOOR
- 06 - REFRIGERATOR DOOR PARTS
- 08 - FRESH FOOD INNER DOOR
- 09 - FRESH FOOD OUTER DOOR (GC2228EED3/5/9)
- 10 - ICE BIN (REV 10)
- 11 - ICE BIN (REV 11)
- 13 - SHELVES & ACCESSORIES
- 14 - WIRING INFORMATION
| Plan number | Part Number | Description | Replacement | Price | ||
|---|---|---|---|---|---|---|
| 1 | 61004847 | BIN, ICE | $0.00 | |||
| 2 | 61004803 | FRONT, ICE BIN | $0.00 | |||
| 2 | 415013-35 | SCREW | $11.46 | |||
| 3 | 61004300 | DOOR, ICE ACCESS | $0.00 | |||
| 4 | 61004869 | SEAL | $0.00 | |||
| 4 | 61004804 | HOUSING, CRUSHER | $0.00 | |||
| 4 | 415013-35 | SCREW | $11.46 | |||
| 5 | 69704-1 | RING, SNAP | $0.00 | |||
| 6 | 69703-1 | WASHER | 489234 | $11.46 | ||
| 7 | 61003336 | RING- DRIV | WP61003336 | $44.67 | ||
| 8 | 61004805 | WIRE HARNESS, AUGER MOTOR | $0.00 | |||
| 8 | 12001775 | ASSY., AUGER MOTOR/YOKE-230/50 | $0.00 | |||
| 8 | 61003324 | SCREW | 2006253 | $11.46 | ||
| 9 | 63052-1 | IMPELLER | WP63052-2 | $52.78 | ||
| 10 | 61004138 | AUGER | $0.00 | |||
| 11 | 69699-1 | CONE, ICE DEFLECTOR | $0.00 | |||
| 12 | 69698-1 | WASHER, CONE STOP | $0.00 | |||
| 13 | 70036-1 | IMPELLER | $0.00 | |||
| 14 | 69755-1 | PLATE, DRIVE | $0.00 | |||
| 15 | 69709-1 | NUT, AUGER | $0.00 | |||
| 16 | 69697-1 | BEARING, SPACER | $0.00 | |||
| 17 | 69696-1 | SPACER, CRUSHER BLADE | $0.00 | |||
| 18 | 69696-2 | SPACER, BLADE | $0.00 | |||
| 19 | 69701-1 | PLATE, IMPELLER | $0.00 | |||
| 20 | 400022-1 | SCREW | WP67006908 | $6.46 | ||
| 20 | 61004848 | EMCLOSURE,ICE | WP61004881 | $151.21 | ||
| 21 | 400022-1 | SCREW | WP67006908 | $6.46 | ||
| 21 | 61003333 | SUPPORT, ENCLOSURE | $0.00 | |||
| 22 | 400026-12 | SCREW | W11233072 | $12.16 | ||
| 22 | 69715-1 | GUIDE, YOKE | $0.00 | |||
| 23 | 69702-3 | BLADE, CRUSHER | $0.00 | |||
| 24 | 69702-2 | BLADE, CRUSHER | $0.00 | |||
| 25 | 69706-1 | BLADE, CRUSHER | $0.00 | |||
| 26 | 69702-1 | BLADE, CRUSHER | $0.00 | |||
| 27 | 69708-1 | LOCK, FIXED BLADE | $0.00 | |||
| 28 | 69705-1 | PIN, BLADE LOCK | $0.00 | |||
| 29 | 69718-1 | DOOR, ICE CRUSHER | $0.00 | |||
| 30 | 61004849 | ROD, CRUSHER CONTROL | $0.00 | |||
| 31 | 61004808 | SPRING, CONTROL ROD | $0.00 | |||
| 32 | 61004809 | BRACKET, CONTROL ROD | $0.00 | |||
| 33 | 61003324 | SCREW | 2006253 | $11.46 | ||
| 33 | 61003649 | SOLENOID | $0.00 | |||
| 34 | 61003539 | YOKE ASSY. | $0.00 | |||
| 35 | 61004850 | SHIELD, WIRE | $0.00 |
*The price can change whitout warning
