Brand: Maytag
Model: MFR50PNAVS - WASHER
05 - DOOR
- 01 - SOAP BOX & TOP COVER ASSEMBLY
- 02 - FRAME PARTS
- 05 - DOOR
- 05 - FRESH FOOD INNER DOOR
- 05 - SECTION
- 06 - BASKET & OUTER SHELL ASSEMBLY
- 07 - REFRIGERATOR DOOR
- 08 - DRAIN & HOSE ASSEMBLY
- 09 - AIR FLOW PARTS
- 09 - ICE MAKER
- 09 - MOTOR & BASKET PULLEY
- 10 - BASE FRAME
- 11 - CABINET
- 13 - BASE FRAME (SERIES 11)
- 14 - CABINET (SERIES 11)
- 15 - TIMER & COIN ASSEMBLY (SERIES 11)
- 16 - SOAP BOX & TOP COVER ASSEMBLY(SERIES 11)
- 17 - DOOR LOCK ASSEMBLY (SERIES 11)
- 18 - DRAIN & HOSE ASSEMBLY (SERIES 11)
- 19 - WATER VALVE & REAR PANEL (SERIES 11)
- 20 - MOTOR & BASKET PULLEY (SERIES 11)
- 21 - BASKET & OUTER SHELL ASSEMBLY(SERIES 11)
- 23 - BEARINGS & TRUNNION ASSEMBLY (SERIES 11)
- 24 - ELECTRICAL COMPONENTS (SERIES 11)
- 25 - CONTROL PANEL (PN MODELS SERIES 11)
| Plan number | Part Number | Description | Replacement | Price | ||
|---|---|---|---|---|---|---|
| 001 | 23001161 | RING, DOOR | $0.00 | |||
| 002 | 23001162 | NUT, ORNAMENTAL (STNLS STEEL) | $0.00 | |||
| 003 | 23001163 | GLASS, DOOR | WP23001163 | $0.00 | ||
| 004 | 23001164 | GASKET, DOOR GLASS | WP23001164 | $0.00 | ||
| 005 | 23001165 | PLATE, HINGE | $0.00 | |||
| 006 | 23001166 | SHIM, HINGE PLATE | $0.00 | |||
| 007 | 23001510 | HANDLE, DOOR | $0.00 | |||
| 007 | 23003631 | HANDLE, DOOR (FRONT) MUST PURCHASE 23003700 ASSY | $0.00 | |||
| 007 | 23003632 | HANDLE, DOOR (BACK) MUST PURCHASE 23003700 | $0.00 | |||
| 007 | 23003700 | HANDLE, DOOR ASSEMBLY HANDLE FRONT & BACK INCLUDED | $0.00 | |||
| 008 | 23003634 | LEVER, DOOR | $0.00 | |||
| 008 | NLA | LEVER, HANDLE | WG03A02017 | $0.00 | ||
| 009 | 23001168 | SHAFT, LEVER | $0.00 | |||
| 010 | 23001169 | SPRING, HANDLE LEVER | $0.00 | |||
| 011 | 23001057 | SPEEDNUT (M3) | $0.00 | |||
| 011 | 23001170 | FASTENER, SPRING (DIA. 3.2) | $0.00 | |||
| 012 | 23001171 | BASE, HINGE | WP23001171 | $0.00 | ||
| 013 | 23001172 | SHAFT, DOOR HINGE | WP23001172 | $0.00 | ||
| 014 | 23001173 | HANDLE, LEVER PLATE | $0.00 | |||
| 015 | 23001175 | SCREW (M6X26 STNLS STEEL) | $0.00 | |||
| 015 | 23002937 | SCREW (M6X26) | $0.00 | |||
| 016 | 23001176 | NUT (M6 STNLS STEEL) | $0.00 | |||
| 017 | 23001158 | SPRING, LOCKWASHER (M6) | $0.00 | |||
| 018 | 23001159 | WASHER (DIA. 14X8.6X1 STNLS)LU | 23001608 | $0.00 | ||
| 019 | 23001177 | SCREW | 8173901 | $11.97 | ||
| 019 | 23001372 | SCREW (M4X10 STNLS STEEL) | $0.00 | |||
| 020 | 23001178 | MICROSWITCH, ACTIVATING PLATE | $0.00 | |||
| 021 | 23001179 | SCREW | $14.70 | |||
| 022 | 23001180 | WASHER (DIA. 10X5.3X1) | $0.00 | |||
| 023 | 23001181 | RING, RETAINING (DIA. 8) | $0.00 | |||
| 024 | 23001182 | BOLT (M6X16 STNLS STEEL) | $0.00 | |||
| 025 | 23001185 | DOORSEAL, TENSION RING | $0.00 | |||
| 026 | 23001186 | DOORSPRING, TENSION SPRING | $0.00 |
*The price can change whitout warning
